EUROLITE DPX-610 DMX Dimmer Pack
Original price was: €474,81.€347,18Current price is: €347,18.
Description
6 x 10A dimmer for DMX & analog signals, connection via terminal blocks
- Universal dimmer pack for professional use
- Can be operated 1-phase or 3-phase
- 6 x 10 A
- DMX-control or analogue control possible
- The DMX-starting address can be adjusted on the device
- Synchronisation of several DPX-610 possible via DMX
- Adjusting the lamp pre-heat
- All modes are displayed via LEDs and the display
- With automatic circuit breaker per channel
- Channel-outputs on the rearpanel via pole connectors
- Only for professional use
| Power supply: | 230-380 V AC, 50 Hz |
| Max. power output: | 13800 W |
| Max. current: | 60 A |
| Number of control channels: | 6 |
| Max. output/channel: | 2300 W |
| Max. current/channel: | 10 A |
| Integrated programs: | 12 |
| Output sockets: | via pole connectors |
| Circuit breaker: | 6 x C 10 A |
| Dimensions (W x D x H): | 410 x 482 x 95 mm |
| Rack installation with 2 U | |
| Minimum mounting depth: | 500 mm |
| Weight: | 8 kg |
Specifications
| Weight | 8,95 kg |
|---|---|
| Dimensions | 0,2000 × 0,5400 × 0,4900 m |
| Color | Black |
| Control | Analog 0-10 V, DMX, Stand-alone |
| Weight kg | 8 |
| Max. output per channel W | 2300 |
| Accumulator | No |
| Number of DMX channels | 6 |
| Max. power output W | 13800 |
| Control Channels | 6 |
| Dimmer/Switcher | Dimmer |
| Current type | three-phase current |
