EUROLITE LED Strip RGBW 4-channel DMX Controller
Original price was: €44,90.€44,48Current price is: €44,48.
Description
4-channel LED controller with DMX interface for RGB LEDs 12-24 V
- Compact LED controller for controlling RGB LEDs (12-24 V) via DMX
- Converts standard DMX512 signals to PWM signals e.g. for driving LED strips
- 4 separate control channels for individual color mixing of red, green, blue and white LEDs
- Built-in programs enable stand-alone operation (individual color selection, color change, color fade, running speed)
- DMX addressing and settings via DIP switches
- Plug-in screw terminals for connecting the LEDs and the power supply
- RJ45 jacks for serial connection
- Rugged black metal housing
| Power supply: | 12-24 V DC |
| Standby current: | <1 W |
| Output power: max. 288 W (12 V), 576 W (24 V) | |
| Output current: | max. 8 A per channel (32 A total) |
| DMX channels: | 4 |
| DMX connection: | screw terminals and RJ45 |
| Dimensions (L x W x H): | 164 x 66 x 38 mm |
| Weight: | 300 g |
| Ecodesign regulation: | Yes |
