OMNITRONIC EM-260 Entertainment Mixer
Original price was: €236,81.€171,13Current price is: €171,13.
Description
OMNITRONIC Entertainment Mixer Series
The modern entertainment industry, especially hotels, bars or theme parks, requires very high standards in quality and features for sound devices.
The OMNITRONIC EM-series is especially designed for this industry and offers the highest flexibility and quality in very small mixer casings.
The EM-series offers a variety of connection possibilities and also convinces by an ergonomic design and easy use.
The special housing design and the state-of-the-art construction are further reasons which make the EM-series the first choice for installers.
The modern entertainment industry, especially hotels, bars or theme parks, requires very high standards in quality and features for sound devices.
The OMNITRONIC EM-series is especially designed for this industry and offers the highest flexibility and quality in very small mixer casings.
The EM-series offers a variety of connection possibilities and also convinces by an ergonomic design and easy use.
The special housing design and the state-of-the-art construction are further reasons which make the EM-series the first choice for installers.
6-channel microphone/line mixer, Silver
- 6 inputs (3 x mic/line and 3 x line) for mixing to 1 stereo output
- Ideal e.g. for karaoke when microphones need to mixed with CDs
- 3 mono input channels mic/line (XLR, bal.), switchable
- 3 stereo line input channels (RCA)
- Clip LED for each microphone channel
- Each microphone input with optional 12 V phantom power
- FX send/return with FX level control
- Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
- Stereo record output (RCA)
- Rack installation, 1 U
| Power supply: | 115/230 V AC, 50/60 Hz |
| Power consumption: | 35 W |
| Inputs MIC 1-3: | XLR |
| Max. input level: | -14 dB |
| Inputs LINE 1-3: | stereo RCA |
| Max. input level: | 24 dB |
| RETURN: | 6.3 mm stereo jack |
| Outputs: | |
| MASTER: | 6.3 mm stereo jack |
| REC: | stereo RCA |
| SEND: | 6.3 mm jack |
| Tone control: | |
| High: | -12 dB to +12 dB/ 10 kHz |
| Bass: | -12 dB to +12 dB/ 100 Hz |
| S/N ratio: | 69 dB |
| Frequency range: | 20-20000 Hz |
| Distortion: | 0.025 % |
| Dimensions (W x D x H): | 482 x 123 x 43 mm (19″, 1 U) |
| Weight: | 2.2 kg |
Specifications
| Weight | 2,6 kg |
|---|---|
| Dimensions | 0,0900 × 0,5300 × 0,2650 m |
| Height cm | 4.3 |
| Weight kg | 2.2 |
| Power supply | 115/230 V AC, 50/60 Hz |
| Power consumption W | 35.00 |
| Master Equalizer | 1 x 2 band tone control Stereo |
