EUROLITE DMX Split 8X RDM Splitter
Original price was: €296,31.€217,77Current price is: €217,77.
Description
Splitter with 8 galvanized isolated outputs, 3/5-pin & QuickDMX XLR sockets
- DMX splitter for splitting one DMX input signal to 8 DMX outputs
- Connections: 1 x DMX input, 1 x DMX feed-through output, 8 x DMX output
- Additional QuickDMX input for wireless reception of DMX signals
- Supports RDM for bidirectional communication over the DMX line
- Switchable filter mode allows all RDM data to be filtered out in order to prevent problems when using fixtures intolerant of RDM
- Input and outputs XLR 3-pin and 5-pin each
- Input and outputs galvanically isolated
- Each DMX output with independent driver and status indicators
- Input and outputs with a set of respective power supply and internal fuse
- Switchable termination resistor
- Rack mounting
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 5 W |
| DMX connection: | 3-pin and 5-pin XLR |
| QuickDMX connection: | 5-pin XLR |
| Dimensions (L x W x H): | 483 x 145 x 45 mm |
| Weight: | 2.5 kg |
Specifications
| Weight | 2,75 kg |
|---|---|
| Dimensions | 0,1100 × 0,5300 × 0,2200 m |
| Weight kg | 2,5 |
| Power supply | 100-240 V AC, 50/60 Hz |
| Power consumption W | 5 |
